HTM Mini-Columns into Hexagonal Grids!

Or at least some wild conjectures to provoke thought! This post assumes that you are familiar with basic HTM theory and are conversant with the concepts of SDRs and HTM minicolumns.

May I be so bold:

First - let’s be clear what I am and am not talking about.

This is about cells that work by forming regular hexagonal grid structures and are not necessarily the same thing as the “grid cells” that are coding some spatial aspect of the surrounding environment.

These grid-forming cells that I will describe combine a sparse collection of mini-columns into larger hexagonal arrays. The cells that form a regular hexagonal array can offer a separate and highly useful tool in the neural network toolbox. They can act to take a local response from a mini-column responding to some locally sensed condition and join it to other local mini-columns that are also responding to what they see of their part of some locally sensed pattern. This is a form of lateral binding.

This behavior takes the place of the spatial pooler in HTM theory.

The Moser/grid cells use these hex-array forming cells to code the external sensed environment so we have a hex-grid signaling an external location (in a grid pattern) to the place cells in the hippocampus.

How meta is that?

Each dot in this picture is a mini-column, exactly as described in the BAMI book.

Q: Why do I describe it as a grid?
A: Because these patterns tile together into larger hexagonal arrays. This is not the goal but a side effect of how the mini-columns work together in a larger collective.

Q: How do these individual mini-columns combine together to form larger coherent patterns?
A: Let us look to see how this hexagonal grid forms.

We start with a single layer 2/3 neuron. What this does is what any neuron does - sense the surrounding area with dendrites and trigger action potentials. The cell may be part of a mini-column but this guy lives upstairs, in the level 2/3 layer; this is where the hex-grid forming happens. Temporal-sensing (HTM) cells may rule the lower levels but up here the hex-grid forming cells control the action.

Note the sneaky intercell axon to tickle certain fellow neurons. It turns out that the spacing is at a fairly standard distance, given by the genetic wiring instructions.

This very technical paper gives a detailed look at these horizontal reciprocal connections; the paper may be a hard read if you are not into cell recording and is heavy on the lab technique.

The distal dendrites form a sensory field looking for local parts of some larger imposed pattern - an arbor. This arbor thing is sort of like an antenna, reaching around for bits of excitement. This cloud is looking for patterns to learn or recognize. These dendrites may have a special visitor connection from other nearby cells that add to the local sensory field, acting as a signal enhancer. (the horizontal reciprocal connections)

These cells entrain on the shared pulses to recruit nearby cells that may be sharing the same pattern of excitation.
From Calvin’s book: “Pyramidal neurons of the superficial neocortex are excitatory to other pyramids and, since they tend to cluster axon terminals at a standard distance (“0.5mm”), some corticocortical cell pairs will mutually re-excite. Though refractoriness should prevent reverberation, even weak positive coupling can entrain oscillators when cells are active for other reasons.”
“Because each pyramid sends horizontal axons in many directions, simultaneous arrivals may recruit a 3rd and 4th pyramid at 0.5mm from the synchronized parental pair. A triangular mosaic of synchronized superficial pyramids thus can temporarily form, extending for some mm (Calvin, Soc. Neurosci. Abstr.'92). At least at the V1-V2 border, the intrinsic horizontal connections change in character and in length, suggesting that mosaics might stay confined to the parent architectonic area, spreading to other areas only via the U-fibers of white matter.”

HTM purist tends to focus on the internals of the mini-column and what it might be doing. I have seen efforts to try and shoehorn the “other” cells in the soup to be some extension of this temporal recognition task. The idea that the cells might be performing housekeeping or communications functions is not given much attention.

This focus on mini and macro columns has produced some marvelous HTM and sparsity papers that have inspired me greatly. Working out the temporal part was worth the price of admission. Still, I have been reading about various processing theories and note that HTM theory does not pay much attention to the rest of the zoo of neurons in the soup. See layer 3 cells talking to each other and to the temporal sensing cells in this picture?

There are inhibitory inter-neurons to do temporal prediction but the rest of the inhibitory neurons don’t seem to have a place in HTM theory.

The two images above are taken from:
Cortical Neurons and Circuits: A Tutorial Introduction

Let’s look at some cortex.

Notice that some of the critters in this zoo (layer II/III pyramidal neurons) seem to be there to enforce sparsity and as a second-order effect - establish a hex-grid.

Most of us have read BAMI or the “thousands of synapses” paper and have some idea of how SDR sensing neurons combine into mini and macro columns to sense an absurdly large number of little bits of patterns and sequences of patterns. How does this fit in with the sparsity/hex-grid pattern forming pyramidal neurons in layer II/III?
Check out this connections diagram. Our friendly layer II/III pyramidal neuron is shown in blue.
Its arbor is sniffing the local neighborhood for some pattern. If found it signals the fellow layer II/III pyramidal neurons and excites proximal inputs of the local column forming neurons. The key to who is “talking” (presynaptic) and who is “listening” (postsynaptic) is given by the color.

In the interest of complete disclosure - column signaling sends much of its output to subcortical structures while layer II/III neurons do much of the cortical map to map signaling. While they work together they seem to be doing different things computationally. Look at this diagram to see where the various populations of temporal column forming vs. hex-grid forming neurons are connected to.

If time allows I have a goodly amount of information suggesting that the cortical-thalamic circuits are important for signaling the recognition of a pattern with some spatial extent and reflecting that to other map areas for both feedback learning and the ignition of the global workspace. This material is too detailed to include in this exposition.

Please look at this diagram to get some idea of the spatial scale of influence of input and output structures of the hex-grid forming neurons vs. the temporal column forming neurons. Their dendrite input arbors are about the same size. This is the scale or scope of any SDR. The lower levels have a much larger reach to excite inhibitory inter-neurons and perhaps run their own horizontal reciprocal connections with other columns.

I will return to a possible role of the inhibitory interneurons later.

So how does this establish a dominant hex-grid in a sea of cheek-to-jowl packing of neurons?
Let’s start with a cell that is sensing some pattern AND being hit with some neighbors that are also recognizing some part of a pattern.

These cells reinforce each other with entrainment. This strong signal will help to find recruits from the surrounding sea of neurons that are sensing something with this special cell spacing.
That leads to the construction of a shared pattern of excitation.

A hexagonal-grid!

This process will continue as long as the ensemble is sensing whatever it is that these cells are tuned to detect - their part in some pattern.

One exciting possibility that counters the model that inhibitory inter-neurons enforce spacing (see further below) is that two or more patterns could exist “inside” of each other. The possibility that this is the source of multiple codes co-existing in the same chunk of cortex at the same time boggles my imagination!

This offers the tantalizing possibility of explaining the 7 +/- 2 to limit for the number of chunks you can hold in your mind at the same time; this is the number of grids that can coexist without interfering with each other.
BTW: Forum member @sunguralikaan suggests that four is a better magical number choice in a different post.
Cognitive Limits Explained? - #2 by sunguralikaan

This also presents a powerful mechanism for the output from these two patterns in this map to be combined in the fiber-bundle linked map(s) that this one is projecting to. Given that there is some slight “dither” in the projection mixing up local patterns the receiving map would see these to patterns “smeared around” and mixed together. This would be a very effective way for the local receptive fields to learn combinations of these two patterns, A & B. This is not strictly a stochastic distribution on each sensed pattern as the projection pattern is fixed; the receiving neurons can reliably assume that this relation between pattern A & B is fixed.


The group of illustrations above is mostly drawn from a wonderful book by William H. Calvin: THE CEREBRAL CODE.
I highly recommend it.

Repeating a key point: all of this is describing what is happening in the L2/3 layer. At this level all we are working with is patterns and NO predictive memory. The L2/3 is also the layer that talks with other maps though the output axons of the L2/3 cell bodies. Likewise, the sensory inputs and rising axons are projected upwards through all layer terminating in the dense mat of L1.

The projecting axons lateral branches do make connections with inhibitory inter-neurons not shown here.

I am certain that there are connections up and down the minicolumn between the layers but I am not ready to state exactly how these connections work. These connections are key to describing the relationship between pattern recognition and temporal prediction. Working out these rules would be key to understanding the training rules of predictive memory.

Now on to the parts relative to hex-grid theory …

Reference my entry on the Project : Full-layer V1 using HTM insights post, #34 where I put figures on the sizes of the various elements for minicolumn spacing.

Each cell in the mini-column has a few dendrites and each one is at least a single SDR and maybe a few.

Referring to this picture from that post - each blue circle is a single mini-column. This is 100 or so cell bodies. Each cell body has its own dendrites - say 10 or so for a nice round number.

The rising projecting axons are also spaced on this 30 µm centers so you can assume that each blue circle also has a rising axon bundle.

The large black circle is the reach of the dendrites (+/- 250 µm, or 500 µm total) for the minicolumn in the center of the diagram. That gives the dendrites in each cell in each mini-column access to about 200 or so rising axon clusters. This can be thought of as a “receptive field” of the blue mini-columns and rising axons within this black circle for this minicolumn. This is all repeated for the next minicolumn. This is the repeating structure for all minicolumns in the cortex.

In this paper Horizontal Synaptic Connections in Monkey Prefrontal Cortex the lateral connections from the L2/3 cells are given as an average of about 500 µm.

The black beam in this picture is the long distance lateral connection between the two minicolumns so that the two minicolumns “receptive fields” connected by this link of the hex grid covers the space with very little overlap and very little missed space.

There are several long distance lateral connections emanating from each cell in the minicolumn to form space covering hex grids. These connections form any cell are not on strict angles or lengths so individual cells can form hex grids with a different angle, spacing, and phasing.

So recapping, every minicolumn has 100 cells that each have 10 dendrites potentially forming at least one SDR, possibly more. (at least 1000 SDRs per minicolumn)

Each Dendrite, if it went in a straight line from the cell body passes at least 7 axon projection clusters and with branching probably many more. This means that the area around each minicolumn is densely sampled with about 1000 branching dendrites which should end up sampling every rising axon cluster within reach of the dendrites.

The lateral connection links these minicolumns so that if they are responding to a learned pattern, even though it is sampled relatively sparsely, all the space in the resonating hex grid pattern is being sampled and bound together into a single larger unique pattern.

Here is a drawing relating the idealized concept to the messy biological bits.

Also, see this post for more on the formation of larger patterns:

These columns have the ability to ability to sense an imposed pattern AND have horizontal reciprocal distal dendrite connection with “far away” columns. These connections form the permanent translation between items at this level of representation and whatever map they are connected to - a perfect translation is always available and in use. Depending on the applied pattern and prior learning - these reinforcing patterns can form regular “shapes.” These drawings show the metrics of these shapes; you see a red test grid and a black reference grid shown before and after a transformation.

There are three front-running models of how hex-grids come to be.

  • Some literature describes how the entorhinal cortex forms grids by some variant of the cells oscillatory pattern (now mostly disproved) or
  • some variant of inhibition between active cells. Many interesting theories for grid spacing use the inhibitory inter-neurons as the traffic cop that enforces spacing. There are compelling reasons to like this theory - first and foremost - because it does explain some of the observed behavior of the entorhinal cortex. It also has the charming property that It’s simple to understand and code.
  • I am siding with a much older excitatory reverberation model as it seems to tie up many of the loose ends that I have seen in various research papers. This may be combined with inhibitory inter-neurons as the traffic cop that enforces spacing. If time allows I will be organizing papers that support this line.

Since much of the literature does assume that inhibition is how hex-grids are formed I will walk through it. In this scenario - our columns are pushy - they squelch the competition.

All three models use the hardware located in layers II/III excitatory pyramidal cells to form hex-grids. The winning cells are spatially sparse in all methods - a very handy feature for anything that works on SDR principles!

It is also possible that multiple hex-grids from the grid-forming neurons can co-exist with the inhibition model in the same map but that local inhibition limits this to some small number. This depends on the interaction of the “spatial reach” of the inhibition field and the grid spacing. I see this as a tunable parameter.

With a pure inhibition model, it is entirely possible for two or more adjacent grids to be formed in the same general area to code spatially separated island of information in the same map. In that case, a computation that intercompares patterns is limited to working on the edges of the islands of information.

I strongly prefer the model of mutual reverberation in layer II/III pyramidal neurons as the hex-grid former as that way multiple items of data can nest together.

So what happens to these patterns - how do they get processed?
First, we need to point out an important property of inter-map connections.

Here is what I think of as “typical” processing done in the cortex; in the following example axons from streams A and C arrive at the proximal and distal dendrites of sheet B. These patterns could come from a sensory stream or from a different region of the cortex.

This is what the receiving map B senses from climbing fibers projected on its proximal and distal dendrites:

No matter what the source, the receiving proximal and distal dendrites start the sampling and sparsification to form a new hex-grid at this level of processing in sheet B. This is the local activity that forms in sheet B and is now sent out to wherever its projected axons go.


You may want to think of each hex-grid-cell & SDR column pair as an amazing puzzle piece that does not quite match up to any real puzzle piece but matches the concept of parts fitting together. Each one can sample the stream of data and learn things about it - in essence- learning the shapes it can be. The shape of the units that make up the hex-grid-forming and temporal-column forming cells is funny - it extends in 3 directions. X, Y, and temporal. The basic function of the ‘T’ in HTM is temporal and the BAMI type model is a change detector.
Coming back to a fundamental relationship:

Layer II/III cells modulates the local column cells. They both sample the same receptive field and they both fire the local inhibition cells, but for different reasons. The two types of cells work together, one to do space, and one to do time. The resulting unit is a basic measure of space-time and you get this little conceptual puzzle piece:

I think many here would recognize the local hyperplane in blue. The yellow item is the predicted hyperplane, shading it with a touch of time. Each column region holds hundreds or thousands of these potential puzzle pieces.

See below: Three hex-grid+temporal-sensing columns are sampling the imposed pattern in gold. As outlined above, these space-time puzzle pieces look for learned patterns and if it sees they it resonates with certain neighbors that also see the part of the pattern that they know. This activation pattern may spread to other groups of cells that are seeing parts of the same larger pattern.

When some pattern comes after this learning (babies are helpless until they learn something) each piece is trying to fit itself into the “picture on the box.” If it able to match up to one of its learned patterns it “snaps into place.” If enough of the pieces click together you can be said to have recognized the sensed pattern at that level. This pattern can be from outside the brain or from some region inside of the brain.

I come back to very basic theory as outlined in the “Why Neurons Have Thousands Of Synapses” paper.
Now consider these three dendrites apart from the rest of the dendrites in each cell.

Each has a sparse SDR that senses patterns – This paper suggests that the number of patterns that any individual segment of dendrites can hold is calculated as a relation of synapse sites and the percentage of active connections along that dendrite (no matter how you count it’s a huge number)

One of the issues mentioned in other posts is relating these dendrites into a larger pattern. SDR theory says that the odds of any of them misfiring with a pattern that is not a match are huge - what happens if these three are highly selective pattern matches are correlated by learning their own part of a larger pattern? In the case above, shown as gold activation fields. The learned pattern at each dendrite doesn’t have to match each other – only the part of the pattern they are learning by themselves. Each puzzle piece is a part of a larger puzzle; each becomes a peak of the mutual-reinforcing activity, a node in a hex-grid. This self-reinforcing property means that the chances of forming the wrong hex-grid from some larger pattern are small but there is a high probability that these sparse puzzle pieces will try to snap together.

The area of the hex-grid stretches as far as there are puzzle pieces matching the spatial-temporal pattern that is being applied to this area. The hex-grid forming properties sample the applied patterns (and surely there are more than one!) and sparsifies that into a new hex-grid.

We have the right facts on hand to estimate a ballpark number of hex-grids that can form in the human brain at the same time:
Column spacing ~= 0.03 mm
Hex-Grid spacing ~= .3 mm
Cortex area ~= 0.3 square meter
(300 mm / 0.3 mm)^2 = number of potential grid centers ~= 10 million simultaneous hex-grid sites.

… and how many patterns can be recognized at each hex-grid site:
Each 0.3 mm spaced grid hosts columns spaced at 0.03 mm, each is capable of being a nucleus of a grid location. Each individual column is capable of representing a large number of potential pieces but I will pick 300 to spitball a number.
(0.3 mm / 0.03 mm)^2 x 300 ~= 30000 code potential puzzle pieces in each grid location.

Someone with a better grasp of combinatorics than I can say how many overall things can be coded with 10 million letter positions with a 30000 letter alphabet but I recognize that it will be a staggeringly large number. This number shoots even higher if multiple hex-grids can co-exist in the same place at the same time.

These hex-grids work on the basic principles of attractors - applied patterns will recall the closest match. This recall process is a competitive process that fishes the best match out of a soup of possible matches, with a cooperative process between potential hex-grid locations to pick the best pattern that simultaneously satisfies both hex-grids recognition process.

For a superb visualization of hex-grids and how of hex-grids coding of different spatial scalings combine to represent a spatial location see this video by Matt Taylor.

THese hex-grid patterns are formed and projected to distant maps. There really would not be much point in just passing the pattern from map to map without any changes Two or more patterns have to project to a target map for some kind of local processing.

What kind of calculation can be performed when grids are combined?

The conjunction of hex-grid patterns has some extraordinary properties.

Let me share the juicy bits; looking at figure 2 to get a glimpse of the computing powers of hex-grids. We see the nodes of hex grids that have different phase/spacing/scaling (figures A & D) and the intersections of those hex-grids. In some places, these nodes line up and reinforce each other. (Figures B & C)

In pictures B & C we see various hex-grid fields representing Moser spatial grid locations with projections to the same areas by different spatial scaled grid size formations. Another way of saying this is checking for correlation in streams of space-time data. OK - just how do we get from a mishmash of the mixed-up signal to some sort of output that makes any sense at all?

In pictures A & D we see the combinations of various projections of some different scaled spatial grid patterns. Each color is from a different projecting area. What happens when these bits line up? That can form remarkably accurate points of local representation. Look back to the last pictures B & C - each of those clusters of blobs is doing this local recognition and summation. Weak peaks combine to make local clusters of strong peaks that drive the learning of this formation of and the future recognition of this correlation of patterns. (Figures A & D)

There is a regular transformation and grouping of these patterns as you move from map to map along the WHAT and WHERE streams. One of the common programming tasks is “parsing.” With a program that is working with a stream of words so it can be a bit harder to see that this is actually a general task that transcends the words. The brain is extracting meanings - patterns - things like syntax, semantics, sequences, and facts about the world. One stream is the WHAT of your perception and one stream is the WHERE of spatial components; how things are shaped or arranged. The process continues until you reach the temporal lobe. At that level what you are perceiving is your experience. This is all a passive process.

Since the usual programming process involves tokens like words it obscures the underlying process. Critters may not talk at all but they are surely doing much the same thing.

The little time/space puzzle pieces are much smaller units of meaning - small enough that it’s easy to miss the trees for the forest. Grouping of these little pieces combines to convey things about the world - some very small, some involving the entire brain map. There is not an exact match up to letters and words but it does help to convey the idea of fragments of meaning combining to parts of the meaning and so on.

Let me share how I see these maps being trained and the general principle of attractor representation.

First - what is an attractor?

If you think of the sea of columns with some pattern of activity impressed on it - how does this soup of learned patterns sort out the one matching or closest matching learned pattern? I see it as both a locally competitive and longer range cooperative process. Each column senses the overall pattern and if there is a match it starts to get a little excited. It’s firing rate goes up as it tries to resonate with the sensed pattern. Those cells that are sharing connections with other time-space puzzle pieces reinforce each other. As the cells get encouragement from other grid cells that are seeing parts that they also recognize the excitement grows. This mutual reinforcement gives the cells that are seeing part of an over-all pattern much more excitement than cells that just see a little bit that matches some prior learning.

The attractor part is that the sensed pattern reaches into the soup of codes and pulls out the matching learned pattern - as if the letters in a bowl of alphabet soup had a complete matching sentence swim up to the surface of the soup. It’s like a magnet draws the pattern (attracts it) out of the soup.

In the early stages, there is no ability to reason out why any pattern is special. As you learn it successive presentations “almost match” and get reinforced. The edges of the recognized pattern get refined as the cells on the edges of the recognized pattern encourage hex-grid cells that are on the fence to learn this pattern. I have to assume that the encouragement of mutual connections increases pattern learning due to the stronger excitement levels. Please recall that this is due to the recurring excitatory connections. As learning continue the learned pattern that is both sensed and projected becomes ever more detailed.

Going BIG!
Keep in mind that this is really interlocking patches of grids with bi-directional bundles of connections to other maps. I see good reasons to assume that mutual reinforcement of pattern recognition extends beyond an individual map to reach from map to map.

More in the next post in this series.

I’ve covered a huge swath of material here. If you have made it this far your head may be spinning trying sort out what bits go where in all this.

Let’s set everything in its place:

  • The location of the columns that form the SDR processing nodes is fixed in space.
  • An individual SDR can only reach as far as the dendrite arbor of a single neuron.
  • The loops of axons that connect the columns in one map to the next are likewise fixed.
  • The 0.5 mm range interconnections between neurons in the same area of the cortex is fixed.
  • What the columns learn - using the proximal and distal dendrites - to recognize a bit of a spatial or temporal pattern, is what changes in this system. This learning is stored in learned connections/synapses along the proximal and distal dendrites. The SDRs. These change as learning progresses. The dendrites may also change and grow.
  • These columns may interact with other columns via learned connections to organize into larger assemblies that take on the characteristics of hex-grids.
  • The array of hex-grid cells is composed of columns that are individually matching parts of patterns using the learned SDRs.

The next post in the series focuses on combining these hex-grids into maps of information.

As always; I welcome your comments and ideas!

How do we create a grid cell system and how do we link it to an HTM?
Free computational neuron models
Grid cells as meta data mapping
How close are you to publishing the next Numenta paper?
What are the flaws in Jeff Hawkins's AI framework?
Grids into Maps!
Network of SpatialPoolers
HTM & columns Working and biological consistence
Basic / Specific Questions about coding HTM
Research topic recommendation for bachelor thesis
Future development of fork + how 'far behind' are we?
A Framework for Intelligence and Cortical Function Based on Grid Cells in the Neocortex
Capacity of a Macrocolumn
Hex Grids & 1000 Brains Theory
HTM Hackers' Hangout - Dec 7
Local inhibition instead of explicit k-winner for spatial pooler
How to generate place fields in grid cells
Grid Cells How Do They Work
What's the difference between layers and levels in the context of the HTM theory?
“Prediction” from the first principles
Biological constraint of grid cells
Stable-Enforced Pooling
Why do members here think DL-based methods can't achieve AGI?
A thought about grid cells in low sensory cortex
Numenta Research Meeting, Nov 25, 2019
Contextual Connections Between SDRs and Spatial Poolers
At how many different minicolumns is connected an unique neuron in a minicolumn?
Discussion about Emotions
"On Intelligence" vs recent developments: What's puzzling me (and some thoughts about grid emergence)
HTM Hackers' Hangout - Jul 6, 2018
Think about nature
Read this first
Should grid cell or displacement cell modules include minicolumns?
Should grid cell or displacement cell modules include minicolumns? encoder algorithm docs
Systems Diagram and understanding of the Neo Cortex
The HTM Spatial Pooler: a neocortical algorithm for online sparse distributed coding
Basic system level diagram of the brain

Moved to #htm-theory:tangential-theories

I am having some trouble figuring out how this process could be combined with traditional HTM concepts. Granted I haven’t fully grasped the process yet (need to read through it a few more times), but I am mainly seeing in this how proximal activations could be utilized to generate (unique/competing) patterns which repeat over the entire matrix. Where do the concepts of minicolmns and predictive states fit into the picture though?

The columns are at al level “before” this all happens.

Please note that the very first image starts with the columns as a done deal

This picks up where HTM leaves off - how do the learning and trained columns work together to form a larger ensemble? How do these larger ensembles work together at higher levels to tie the various maps together?

At several points, this explanation assumes that the HTM-neurons/column is doing its job exactly as the BAMI book describes and we are either accepting bits of patterns into the proximal connections or sending finished patterns out through axons to local or distance fields of HTM columns.

This does add the detail of the interaction of the layer ii & III pyramidal neurons to collect up this activity and shape it at a larger spatial scale, enforcing sparsity and forming grids.

BTW: The grids can be a very small part of the area/maps. I see no reason that multiple different grid patterns could not be forming at the same time in different parts of the map, each representing different parts of the sensed pattern as perceived by that part of the map.

Ok, so the grid could be a grid of minicolumns (in your example, it is representing potential hexagonal-shaped groupings of minicolumns viewed from above).

One way I could see that being used is to “fill in” the space between extremely sparse activations up to a target sparsity. I’m thinking this might be usable in a new temporal pooling strategy, in which the borders where patterns meet could potentially be less sparse and thus combined with topology in the SP process to produce representations of two combined features made up of cells that are physically closer to each other.

Yes, an excellent analysis of some of the fine-grained implications of this system.

Going more towards the macro scale - look to the linked Calvin document to see how he uses these structures to do larger scale representations and computations.

All back in the 1990’s, long before HTM was a thing.

Thanks, yes I am still reading through and digesting the Calvin document you linked. I probably will need to write up some implementations and play around with various parts to get a feel for them before I’ll be able to mix-and-match with other concepts.

I am starting to see a possible synergy with concepts from @dwrrehman’s pooling strategy. I have been tinkering around with a variation if that process for a while, so that is probably why it is what is standing out to me :slight_smile:

I read papers and try to reconcile what the different authors are seeing to drive their conclusions.
Marr’s Computational and Algorithmic levels.
You write code to see how an idea works in practice; we all come at this from different directions.
Marr’s Implementational Level.


Interesting! Any ideas on exactly how the triangular grid firing patterns work(connect) with the randomly sparse firing patterns to combine WHAT & WHERE? (On micro scale or the algorithm on macro scale)

Yes - I am slowly working through the explanations and drawing for that portion. It is somewhat more complicated and that is taking some time.

I am also working on the lizard brain from the tip of the toe through to the forebrain with details of the lizard brain command structures.

I am also working on the interaction between the lizard brain and the cortex. Lots of drawings needed here. This also gets heavily into the counterflow of information back down towards the sensory streams.

I am also working on the capture and formation of semantic content from the sensory stream through to the temporal lobe.

Each of these is about as detailed as what I have going here for the grids and I can see how they all fit together.

Only so many hours in a day and I still have a demanding day job.

It’s a great life if you don’t weaken!

1 Like

That’s great. I would like to know your current thoughts in detail. I have some theory of how the grid patterns might be working at different scales and layers to form representations about location at different abstract “space grids” and then later combining into groups of locations or multiple space-grids. This is like combined manifolds you mentioned in another thread. I think your explanation of combinations of grids might come handy in the theory.

Please read the linked Calvin document - it may help avoid reinventing the wheel.

There are nice ideas in the writing. The most interesting for me was the implications of local inhibition at higher levels of abstraction. New relations emerge. We mostly go with global inhibition in HTM layers at the moment which may cost us some emerging relations when the hierarchy is in place. It was probably hard to structure but the general flow may be represented better, I was kind of lost on the thought process at times. On a different note, it would be great if you could find a way to test some of the ideas here at small scales to be certain about their implications before moving forward at various stages to make the best of your time. How you would do that, I do not really now. Thanks for the writeup.


Man oh man, this post is great! I’ve wanted to get a quick getup with the theory between HTM, the layers and all that jazz. And this post seem to be the perfect starting point. The vulgarized explanations with all the graphics are godsend.

You’ve truly outdone yourself and shown what is high quality posting Bitking!


Check out Matt Taylor’s superb Grid cells presentation in the HTM school!

Matt points out that thinking of grid cells as maps of a room vastly underestimates the general potential of mentally mapping any arbitrary 2D space.

Matt demonstrates the relationship between SDR representation and grid coding. I outline multiple methods of using HTM to form grids in this post. There are some pieces to put together but this combination represents a potential tool to code a reasonably intelligent agent. So much to do to tie this all together.

He also introduces the concept that grid cells might be used in the neocortex to represent all objects in the brain, not just locations relative to an agent’s body. The papers below show how general mental cognition may well rest on this ability to mentally represent and manipulate space.

Here are the links referenced in the video comments:

2014 Nobel Prize Lecture:

Referenced papers:
The representation of space in the brain (Roddy M. Grieves, Kate J. Jeffrey):

Network Mechanisms of Grid Cells (Edvard Moser, May-Britt Moser, Yasser Roudi):

Computational Models of Grid Cells (Lisa M. Giocomo, May-Britt Moser, Edvard Moser):

Evidence for grid cells in a human memory network (Christian F. Doeller, Caswell Barry, Neil Burgess): Evidence for grid cells in a human memory network

Mapping of a non-spatial dimension by the hippocampal-entorhinal circuit (Dmitriy Aronov, Rhino Nevers, David W. Tank):

Organizing conceptual knowledge in humans with a gridlike code (Alexandra O. Constantinescu, Jill X. O’Reilly, Timothy E. J. Behrens):

Organizing Conceptual Knowledge in Humans with a Grid-like Code
Alexandra O. Constantinescu1, Jill X. O’Reilly, Timothy E. J. Behrens
It has been hypothesized that the brain organizes concepts into a mental map, allowing conceptual relationships to be navigated in a similar fashion to space. Grid cells use a hexagonally-symmetric code to organize spatial representations and are the likely source of a precise hexagonal symmetry in the functional magnetic resonance imaging signal. Humans navigating conceptual two-dimensional knowledge showed the same hexagonal signal in a strikingly similar set of brain regions to those activated during spatial navigation. This grid-like signal is consistent across sessions acquired hours and more than a week apart. Our findings suggest that global relational codes may be used to organize non-spatial conceptual representations and that these codes may have hexagonal grid-like pattern when conceptual knowledge is laid out in two continuous dimensions.


I could click on the aforementionned link in several ways without the counter showing the slightest tremor, if that is of any comfort to you.

Sorry for my question, which may simply come too early for my current understanding. I haven’t digested all this yet. But… well, grid cells and their power for computing a position in the environment’s topology, as presented in the paper “Connecting multiple spatial scales to decode the population activity of grid cells”, versus a cortical grid-like topology seem like two entirely different matters to me. Granted, I myself had random thoughts which erred towards that same direction, but what makes you so confident that there would be some actual correlation ?
(Still haven’t read Calvin. I’d like to make clear that I’m not refusing the idea of grids in the brain topology here - although I may raise same concerns as Paul for a usage with current HTM model. I’m simply curious about the correlation you obviously sense between 2014-nobel-grid-stuff and grids within cortex itself)


Different levels of representation
Local topology forms grids of various spacing.
It’s baked in.
When these different sections do their grid forming thing it favors a particular spacing due to its genetic wiring in that area. When the efferent fiber tracts from different areas converge on some distant map there are samples of multiple scaling represented in the combined population of activation. This behavior is at the H level of HTM theory - topology matters greatly at this level.

I strongly suspect that all grid-forming areas are built up from multiple semanticly related sources. I may be putting the cart before the horse here - the fiber tracts that combine in an area define a semantic meaning that is the intersection of the semantics of the source areas - which may seem in-turn be the semantic combination of its sources.

I think of the purpose of the grid topology is to form a united excitation pattern where the grid members are all recognizing the same thing at the same time. This forms and projects this knowledge to the next map: it’s saying that “I saw this thing at this place in my sensory space.” Instead of a few random bits, you have a (sparse) spatially widely distributed pattern; way bigger than the dendrite reach of any single pyramidal cell.

This locally addresses what (for some) is THE holy grail problem in neural representation: Binding.

I believe that inter-map reciprocal projections extend this pattern formation to global binding.


Very well said. I think this notion of referring to the grid mapping with reference to the cortices own natural processing space has its own significance.
The idea of forming semantically spaced grids with respect to the sensory information and their semantics is different and more complex in my mind. It calls for its own additional pattern processing.


Can you elaborate?
